Product Details

Full Description:

Manufacturer	Rockwell Automation / Allen-Bradley
Brand	Allen-Bradley
Product Type:	Analog Input Module
Part Number/Catalog No.	1769-IF4XOF2
Product Line	CompactLogix
No. of Inputs:	4 inputs; Differential or Single Ended
Module Type	Analog Input/Output Combo Module
Input Type	Analog Input
Number of outputs:	2 Single ended
Power Supply Distance rating:	8
Communication Cable	4 Point
Input / Output current range:	0-21 mA
Shipping Weight	2 pounds
Current signal normal ranges:	0-20mA; 4-20 mA
Shipping Dimensions	8 x 8 x 5 inches
Current signal full range:	0-21 mA; 3.2 - 21 mA.
Series	A and B

Input / Output voltage range:	0-10.5VDC
Voltage signal normal ranges:	±10V DC, 0 …10V DC, 0…5V DC, 1…5V DC
Inputs	4 Isolated Differential
Voltage signal full range:	±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC
Converter Type	Delta Sigma
Compatible Controllers:	CompactLogix / MicroLogix 1500
Replacement Terminal Block	1769-RTBN18
Resolution:	8 bits plus sign (Sign is always positive)
Wire Type	Copper-90 degrees Celsius
Wire Size (Solid)	22-14 AWG
Channel Diagnostics:	Over- or under-range by bit reporting, process alarms
Slot width:	1
UPC	10612598286215
Recommended cable:	Belden™ 8761 (shielded)
UNSPSC	32151705
Dimension:	118 mm (height) x 87 mm (depth) x 35 mm (width) [52.5 mm (width) for 1769-IF8] Height including mounting tabs is 138 mm 4.65 in (height) x 3.43 in (depth) x 1.38 in (width) [2.07 in (width) for 1769-IF8] Height including mounting tabs is 5.43 in

Part No : 1769-IF4XOF2

ALLEN BRADLEY

REQUEST QUOTE

Brand:	AUTOMATION PRODUCTS (PLC , HMI, DRIVES)
Condition:	Brand New
Quantity:	0
Status:	OUT IN STOCK
Stock Location:	GHAZIABAD
Item Code:	85389000
Usage Application:
Power Consumption:
Power Source:
Power Type:
Material:
Automation grade:
Size:
Description:	Combination Module, CompactLogix, Analog, 6 Point, 4 Current or Voltage Input, 2 Current or Voltage Output, 8 Bits Resolution
