| General specifications |
| Detection range |
0 ... 500 mm |
| Reference target |
standard white 200 mm x 200 mm |
| Light source |
IRED , 880 nm |
| Light type |
infrared |
| Diameter of the light spot |
approx. 80 mm at 500 mm |
| Ambient light limit |
10000 Lux |
| Indicators/operating means |
| Operation indicator |
LED green |
| Function indicator |
Dual color-LED, yellow/green
yellow: switch state
green: power on
flashing: stability control |
| Control elements |
Sensing range adjuster |
| Electrical specifications |
| Operating voltage |
10 ... 30 V DC , class 2 |
| Ripple |
10 % |
| No-load supply current |
≤ 25 mA |
| Time delay before availability |
≤ 25 ms |
| Output |
| Switching type |
light/dark on electrically switchable |
| Signal output |
1 PNP output, short-circuit protected, reverse polarity protected, open collector |
| Switching voltage |
max. 30 V DC |
| Switching current |
max. 100 mA |
| Voltage drop |
≤ 2.5 V |
| Switching frequency |
500 Hz |
| Response time |
1 ms |
| Conformity |
| Product standard |
EN 60947-5-2 |
| Standard conformity |
| Standards 2 |
UL 508 |
| Approvals and certificates |
| EAC conformity |
TR CU 020/2011 |
| UL approval |
cULus Listed, Type 1 enclosure |
| CCC approval |
CCC approval / marking not required for products rated ≤36 V |
| Approvals |
CE, cULus Listed 57M3 (Only in association with UL Class 2 power supply; Type 1 enclosure) |
| Ambient conditions |
| Ambient temperature |
-25 ... 55 °C (-13 ... 131 °F) |
| Storage temperature |
-40 ... 70 °C (-40 ... 158 °F) |
| Mechanical specifications |
| Degree of protection |
IP67 |
| Connection |
4-pin, M12 x 1 connector |
| Material |
|
| |
Housing |
brass, nickel-plated |
| |
Optical face |
PC |
| Mass |
45 g
|
